Validating HTTPS Cache Peers for Squid

January 6, 2020 – 12:38 am

I have a squid proxy server that uses a long list of authenticated cache peers in a round-robin configuration. The process looks something like this:

The key to getting this setup working well is to weed out unresponsive cache peers. In my case the proxies used as cache peers are ‘premium’ – I pay for the service. The vendor provides me with a regularly-updated list of working proxies. Or so they claim. I don’t how they’re checking this list, but almost always it requires some cleaning.

I wrote a little script that in a couple of minutes can go though a list of about three thousand proxies and select a few hundred that are sufficiently responsive. The script makes sure the proxy’s response meets these four conditions:

The proxy responds to a request.
The response arrives within the specified time window.
The response contains an IP address.
This IP address is not your own.

The last line of my /etc/squid/squid.conf contains this directive:

include /etc/squid/peers.conf

1	include /etc/squid/peers.conf

The peers.conf file looks something like this:

cache_peer ${proxy_ip} parent ${proxy_port} 0 proxy-only round-robin login=${user}:${password}
cache_peer_access ${proxy_ip} allow all
...

cache_peer ${proxy_ip} parent ${proxy_port} 0 proxy-only round-robin login=${user}:${password}

cache_peer_access ${proxy_ip} allow all

...

The script will go through the list of proxies and run about 200 curl instances at a time. Depending on your system’s resources, you may adjust this value (maxthreads). I am expecting the proxy to provide output within 5 seconds (timeout_01), but you may want to adjust this as well, depending on how picky you can afford to be.

The very last step would be to reload squid, making it re-read the configuration. Should something go wrong, the original peers.conf file will be preserved with the current date extension. Give this script a shot and, should everything work out well, add it to cron to run at least daily.

And here is the script (also available in my GitHub repo):

#!/bin/bash
#
#                                      |
#                                  ___/"\___
#                          __________/ o \__________
#                            (I) (G) \___/ (O) (R)
#                                   Igor Os
#                           igor@comradegeneral.com
#                                 2019-12-14
# ----------------------------------------------------------------------------
# Script description
# Documentation URL: https://
# Validate a list of HTTPS proxies and generate Squid peer configuration
#
# CHANGE CONTROL
# ----------------------------------------------------------------------------
# 2019-12-14  igor  wrote this script
# ----------------------------------------------------------------------------
configure() {
basedir="/var/adm/bin/squid"
infile="${basedir}/proxyips.txt"
squiddir="/etc/squid"
squidpeers="${squiddir}/peers.conf"
creds="user:pass"
proto="https"
testurl="${proto}://ipecho.net/plain"
maxthreads=200
timeout_01=5
# realip="your actual external IP"
realip="$(curl -q -s0 -k "${testurl}")"
if [ -z "{realip}" ]
then
echo "Unable to determine your actual external IP. Exiting..."
exit 1
fi
}
backup_do() {
/bin/mv "${squidpeers}" "${squidpeers}_$(date +'%Y-%m-%d')" 2>/dev/null
}
proxy_check() {
my_ip="$(/usr/bin/timeout ${timeout_01} /usr/bin/curl --silent --proxy "${line}" --proxy-user "{creds}" "${testurl}" | grep -oE -m1 "([0-9]{1,3}\.){3}([0-9]{1,3})")"
if [ ! -z "${my_ip}" ] && [ $(echo "${my_ip}" | fgrep -c "{realip}") -eq 0 ] && [ $(echo "${my_ip}" | grep -coE "([0-9]{1,3}\.){3}([0-9]{1,3})") -eq 1 ]
then
echo "${line}"
ip=$(echo ${line} | awk -F: '{print $1}')
port=$(echo ${line} | awk -F: '{print $2}')
echo "cache_peer ${ip} parent ${port} 0 proxy-only round-robin login={creds}" >> "${squidpeers}"
echo "cache_peer_access ${ip} allow all" >> "${squidpeers}"
fi
}
export -f proxy_check
# RUNTIME
configure
backup_do
i=1
cat "${infile}" | sort -Vu | shuf | while read line
do
if [ ${i} -le ${maxthreads} ]
then
proxy_check &
(( i = i + 1 ))
else
i=1
sleep ${timeout_01}
fi
done
sleep ${timeout_01}
/sbin/service squid reload

#!/bin/bash

# |

# ___/"\___

# __________/ o \__________

# (I) (G) \___/ (O) (R)

# Igor Os

# igor@comradegeneral.com

# 2019-12-14

# ----------------------------------------------------------------------------

# Script description

# Documentation URL: https://

# Validate a list of HTTPS proxies and generate Squid peer configuration

# CHANGE CONTROL

# ----------------------------------------------------------------------------

# 2019-12-14 igor wrote this script

# ----------------------------------------------------------------------------

configure() {

basedir="/var/adm/bin/squid"

infile="${basedir}/proxyips.txt"

squiddir="/etc/squid"

squidpeers="${squiddir}/peers.conf"

creds="user:pass"

proto="https"

testurl="${proto}://ipecho.net/plain"

maxthreads=200

timeout_01=5

# realip="your actual external IP"

realip="$(curl -q -s0 -k "${testurl}")"

if [ -z "{realip}" ]

then

echo "Unable to determine your actual external IP. Exiting..."

exit 1

}

backup_do() {

/bin/mv "${squidpeers}" "${squidpeers}_$(date +'%Y-%m-%d')" 2>/dev/null

}

proxy_check() {

my_ip="$(/usr/bin/timeout ${timeout_01} /usr/bin/curl --silent --proxy "${line}" --proxy-user "{creds}" "${testurl}" | grep -oE -m1 "([0-9]{1,3}\.){3}([0-9]{1,3})")"

if [ ! -z "${my_ip}" ] && [ $(echo "${my_ip}" | fgrep -c "{realip}") -eq 0 ] && [ $(echo "${my_ip}" | grep -coE "([0-9]{1,3}\.){3}([0-9]{1,3})") -eq 1 ]

then

echo "${line}"
